- Reliable engine and wet axles. Frame designed for high resistance and efficient load distribution ensuring longer life.
- Tandem gear pump enables fine grading and has flow control via dashboard switch. Power assisted service brakes reduces fatigue.
- Spacious Cab offers wide range of view. More ergonomically designed handrail and steps for safe and easy entry/exit.
- Open front grill gives easy access for cooling system cleaning which is great for dusty conditions, battery access and electric maintenance.
CLG766A
Operating weight:
8100 kg
Diging depth:
4440 mm
CLG766A
Unit：
- Metric
- U.S
Product Features
CLG766A
CLG766A
CLG766A
CLG766A
Specifications
| Gross Power | 74.5 kW (101 hp) @ 2200 rpm |
| Net Power | 72 kW (98 hp) @ 2200 rpm |
| Operating Weight | 8100 kg |
| Maximum Digging Depth | 4440 mm |
| Maximum speed | 5.9 - 36 km/h |
| Turning Radius Outside of Front Tire w/o single braking | 4400 mm |
| Turning Radius Outside of Bucket w/o single braking | 5554 mm |
| Turning Radius Outside of Front Tire w/ single braking | 3450 mm |
| Bucket Breakout Force, General bucket | 59.3 kN |
| Bucket Digging Force | 58.2 kN |
| Maximum Dump Height (Loading) | 2691 mm |
| Loading Height (Digging) | 3554 mm |
| Model | Perkins 1104D-44TA |
| Emission Standard | EPA Tier 3 / EU Stage IIIA |
| Standard Bucket Heaped Capacity | 1 m? |
| Standard Backhoe Bucket Heaped Capacity | 0.2 m? |
| Gross Power | 70 kW (95 hp) @ 2200 rpm |
| Net Power | 68 kW (92.4 hp) @ 2200 rpm |
| Operating Weight | 8100 kg |
| Maximum Digging Depth | 4440 mm |
| Maximum speed | 5.9 - 36 km/h |
| Turning Radius Outside of Front Tire w/o single braking | 4400 mm |
| Turning Radius Outside of Bucket w/o single braking | 5554 mm |
| Turning Radius Outside of Front Tire w/ single braking | 3450 mm |
| Bucket Breakout Force, General bucket | 59.3 kN |
| Bucket Digging Force | 58.2 kN |
| Maximum Dump Height (Loading) | 2691 mm |
| Loading Height (Digging) | 3586 mm |
| Model | Weichai WP4G95E221 |
| Emission Standard | EPA Tier 2 / EU Stage II |
| Standard Bucket Heaped Capacity | 1 m? |
| Standard Backhoe Bucket Heaped Capacity | 0.2 m? |
